Canon CanoScan Lide 400 / 2996C010A Scanner

Canon DR-C240 Document Scanner

Type: Desktop Page Feed Scanner

Scanning Sensor Unit: CMOS CIS 1 Line Sensor

Optical Resolution: 600 dpi

Light Source: RGB LED

Scanning Direction: Front / Rear / Bidirectional

Interface High speed USB 2.0

Dimensions (WxDxH)

With Trays Closed 291 x 253 x 231 mm

With Trays Open 291 x 603 x 363 mm

Weight: Approx. 2.8 kg

Power Requirements: AC 100-240 V (50/60 Hz)

Power Consumption

Scanning 19 W or less

Sleep Mode: 1.4 W or less

When Power Off: 0.1 W or less

Operating Environment: 10°C - 32.5°C

Humidity: 20 - 80% relative humidity

Environmental Compliance: RoHS and ENERGY STAR

Scanning Technical Specifications

Black and White 45 ppm / 90 ipm

Color: 30 ppm / 60 ipm

Output Resolution: 150 x 150 dpi, 200 x 200 dpi, 240 x 240 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi

Output Mode: Black & White/Error Correction/ Advanced Text Enhancement, Advanced Text Enhancement II, 8-bit Grayscale (256 Levels), 24-bit Color

Recommended Daily Continuous Operation: Approximately 4000 scans

Document Properties

Width 50.8 - 216 mm

Length: 54 - 356 mm

Thickness: 27 - 209 g/m² (0.06 - 0.25 mm)

Long Document Mode: 3000 mm Maximum

Business Card Scanning

Size: 50.8 x 85 mm or larger

Thickness: thinner than 0.45 mm

Plastic Card Scanning

Size: 53.9 x 85.5 mm

Thickness: 0.76 mm (Embossed Card up to 1.4 mm supported)

Passport Scanning: Thickness up to 4 mm (via carrier guide)

Paper Separation Decelerating Cylinder Method

Feeding Capacity: 60 sheets (80 g/m²)

Features: Auto Page Size Detection, Curvature Correction, 3D Color Correction, Color Filtering (RGB), Color Enhancement (RGB), Auto Color Detection, Shadow Clipping, MultiStream, Switchable Gamma Settings, Blank Page Skip, Foil Mode, Scan Area Adjustment, Batch Sorting with blank white sheet or correction code, Moiré Reduction, Anti-nesting/Background Removal, Contrast Editing, Background Softening, Shadow Cropping, Auto Resolution Adjustment, Double Feed Release Mechanism, Double Feed Detection (Ultrasonic Sensor, Length)

Bundled Software: Windows ISIS /TWAIN Driver (Windows VISTA SP2/ 7 SP1/ 8/ 8.1/8.1/10 Server 2008 R2 SP1 / Server 2012 R2)

CapturePerfect, CaptureOnTouch, eCopy PDF Pro Office, Kofax VRS

Add-on EMC Captiva Cloud Runtime Controls

Consumables: Cylinder Change Kit, Carriage guide (Passport), Carriage Guide (A4)
